Ajax DomeCam Mini HL 8MP 2.8mm White

Ajax DomeCam Mini HL 8MP 2.8mm White

The Ajax DomeCam White 8MP is a wired AI-powered security IP camera designed for detailed wide-area surveillance indoors and outdoors. Its 8MP CMOS image sensor delivers video resolution up to 3840 × 2160, while the fixed 2.8mm f/1.6 lens provides a broad horizontal viewing angle of up to 110°.

Additionally, hybrid infrared and white LED illumination supports low-light surveillance, while 120 dB True WDR helps retain useful detail in scenes with challenging contrasts. AI-powered recognition further allows the camera to identify people, pets and vehicles.

8MP 4K Video

The DomeCam Mini HL uses an 8MP CMOS 1/2.7-inch image sensor.

Supported resolutions include:

• 8MP: 3840 × 2160
• 6MP: 3072 × 1728
• 5MP: 2944 × 1656
• 5MP: 2880 × 1620
• 5MP: 2592 × 1944
• 4MP: 2560 × 1440
• 3MP: 2304 × 1296
• 2MP: 1920 × 1080
• 0.6MP: 1024 × 576

The camera supports a frame rate of up to 20 fps.

Furthermore, image rotation can be configured at:

• 0°
• 180°

2.8mm Wide-Angle Lens

The camera uses a fixed 2.8mm lens with a maximum aperture of f/1.6.

Field of view:

• Horizontal: 100°–110°
• Vertical: 50°–60°
• Diagonal: 125°–135°

Therefore, the 2.8mm lens provides broad surveillance coverage and is well suited to entrances, reception areas, retail spaces, courtyards, parking areas and other locations where a wide field of view is required.

DORI Distance

For the 8MP / 2.8mm configuration:

• Detection: Up to 90m
• Observation: Up to 36m
• Recognition: Up to 18m
• Identification: Up to 9m

These distances provide a useful reference when planning camera positioning for different surveillance objectives.

Hybrid Illumination

The DomeCam Mini HL combines infrared and white LED illumination.

Maximum illumination distance:

• White LED: Up to 15m
• IR LED: Up to 15m

Intelligent lighting control automatically adjusts the intensity of both lighting systems in real time.

As a result, the camera helps prevent overexposure while maintaining visibility of objects positioned at different distances in low-light environments.

Low-Light Performance

Minimum illumination:

• Colour: 0.005 lx
• Black and White: 0 lx

The signal-to-noise ratio is more than 52 dB.

Therefore, the camera can maintain useful surveillance detail even under very low ambient lighting conditions.

True WDR Image Processing

The camera provides 120 dB True WDR.

True WDR helps balance bright and dark areas within the same scene. Consequently, details can remain clearer around entrances, windows, doors and other environments with significant differences in lighting.

AI Object Detection

The camera detects motion through software image-frame analysis.

Built-in AI recognises:

• People
• Pets
• Vehicles

Therefore, the system can distinguish relevant objects and support more targeted surveillance events.

Ajax DomeCam White 8MP Video Transmission

The camera uses JetSparrow, the fast and encrypted peer-to-peer video protocol developed by Ajax Systems.

Supported network protocols include:

• HTTP
• HTTPS
• TCP/IP
• IPv4
• RTSP
• UDP
• DHCP
• DNS

Additionally, the camera conforms with ONVIF Profile S for compatible integrations.

Visual Verification Of Ajax Alarms

The DomeCam Mini HL supports visual verification scenarios within Ajax security systems.

For example, Ajax detectors can trigger selected cameras to begin recording when an alarm occurs.

The recorded event is then delivered to the compatible Ajax mobile or desktop monitoring application.

As a result, users can quickly review video associated with a security event.

Video Storage

The camera supports:

• MicroSD card storage
• Ajax NVR

The camera supports microSD cards up to 256GB.

The memory card should be Class V30 or faster.

MicroSD card is not included.

Built-In Microphone

The DomeCam Mini HL includes a built-in microphone.

When the corresponding settings are enabled, the camera can record audio at the monitored location.

Supported audio codecs include:

• G711-ULAW
• G711-ALAW
• G726
• G722

Privacy And Access Control

Ajax provides configurable privacy controls for video surveillance.

The device owner can manage access rights for:

• Ajax mobile app users
• Installers
• Monitoring company operators through Ajax PRO Desktop

Therefore, the owner controls who can access video streams, event history and device settings.

Security Protection

The DomeCam Mini HL includes several technologies designed to protect communication and device integrity.

These include:

• mTLS: Encrypted connection for data protection
• Ajax Cloud Authentication
• Secure Boot: Protection against firmware spoofing
• OTA Signature Verification: Secure automatic firmware updates

Together, these technologies help protect video communication and camera operation.

Network Connectivity

The camera connects through a self-adaptive Ethernet interface.

• Port: 1 × RJ-45
• Ethernet: 10/100 Mbps

Supported protocols include:

• HTTP
• HTTPS
• TCP/IP
• IPv4
• RTSP
• UDP
• DHCP
• DNS
• ONVIF Profile S

Power Supply

The camera supports both PoE and external 12V DC power.

PoE

• Standard: IEEE 802.3at/af
• Maximum Power Consumption: Up to 8.2W
• Average Power Consumption: Up to 7.7W

12V DC

• External Supply: 12V DC ±20%, 1A
• Maximum Power Consumption: Up to 7.1W
• Average Power Consumption: Up to 6.7W

Therefore, installers can select the most suitable power option for the available infrastructure.

Device Specifications

• Camera Type: Wired AI-powered security IP camera
• Image Sensor: 8MP CMOS, 1/2.7-inch
• Maximum Resolution: 3840 × 2160
• Maximum Frame Rate: Up to 20 fps
• Lens: 2.8mm fixed
• Maximum Aperture: f/1.6
• Horizontal Field of View: 100°–110°
• Vertical Field of View: 50°–60°
• Diagonal Field of View: 125°–135°
• DORI Detection: Up to 90m
• DORI Observation: Up to 36m
• DORI Recognition: Up to 18m
• DORI Identification: Up to 9m
• Dynamic Range: 120 dB True WDR
• Minimum Illumination – Colour: 0.005 lx
• Minimum Illumination – B/W: 0 lx
• SNR: More than 52 dB
• IR Illumination: Up to 15m
• White LED Illumination: Up to 15m
• Motion Detection: Software image-frame analysis
• AI Detection: People, pets and vehicles
• Video Codecs: H.265 and H.264
• Built-In Microphone: Yes
• Audio Codecs: G711-ULAW, G711-ALAW, G726, G722
• MicroSD Support: Up to 256GB
• Recommended MicroSD: Class V30 or faster
• Ethernet: 10/100 Mbps RJ-45
• ONVIF: Profile S
• Video Protocol: JetSparrow
• PoE: IEEE 802.3at/af
• External Power: 12V DC ±20%, 1A
• Dimensions: 114 × 114 × 67mm
• Weight: 430g
• Operating Temperature: -30°C to +60°C
• Operating Humidity: Up to 90%
• Protection Class: IP66
• Impact Protection: IK08
• Colour: White

Compatibility

The DomeCam Mini HL supports integration with:

• Ajax NVR
• Ajax security systems
• Ajax mobile applications
• Ajax PRO Desktop
• Compatible ONVIF Profile S systems
• Compatible RTSP video systems
• MicroSD storage up to 256GB

Complete Set

The package includes:

• Ajax DomeCam Mini HL 8MP 2.8mm White
• Installation template
• Installation kit
• Quick start guide

MicroSD card is not included.

Professional Security Solution

The Ajax DomeCam Mini HL 8MP 2.8mm White combines 4K UHD video, wide-angle surveillance, AI-powered object recognition, hybrid illumination and 120 dB True WDR in a compact professional IP security camera.

Furthermore, its 2.8mm lens provides up to a 110° horizontal viewing angle, allowing broad areas to be monitored from a single camera position.

Meanwhile, the IP66 and IK08 enclosure supports demanding indoor and outdoor installations. The white finish provides a clean installation option for light-coloured ceilings, walls, residential properties, retail environments and commercial premises.
