Ajax NVR DC 8-CH White

Ajax NVR DC 8-CH White

The Ajax 8 channel NVR is a network video recorder designed to manage and record video from up to eight compatible IP cameras. It supports video streams up to 4K resolution and provides integrated video management through Ajax mobile apps and PRO Desktop.

Powered from a low-voltage DC supply, the NVR DC is designed for indoor security installations where reliable video recording, event management and Ajax alarm verification are required.

Video Stream And Recording

The Ajax NVR DC supports up to 8 video channels with video resolution of up to 4K at 25/30 FPS.

Supported video decoding formats include:

• H.265
• H.264

The recorder supports total bandwidth of up to 100 Mbit/s.

Storage

The NVR supports:

• 1 × SATA storage drive
• Maximum drive capacity: 16 TB
• 2.5″ or 3.5″ form factor
• HDD or SSD
• Supported drive power consumption: up to 7 W

HDD or SSD is not included.

Detection Technology

The NVR includes built-in software for detecting movement within the video frame.

Motion detection can use either:

• NVR DC image analysis
• Compatible camera algorithms

The preferred detection method can be selected through an Ajax app.

Ajax 8 Channel NVR Video Management

The Ajax video management system provides centralised control of connected cameras.

Features include:

• Video wall combining images from connected cameras
• Event filters
• Timeline with smooth video preview
• Camera recording triggered by Ajax alarm scenarios
• Video access through mobile and desktop applications

When configured as part of an alarm scenario, Ajax detectors can trigger selected cameras to begin recording. The resulting video can then be delivered through Ajax mobile and desktop applications.

Wireless Communication

The NVR provides both Ethernet and Bluetooth communication.

Ethernet

• Up to 100 Mbit/s

Bluetooth

• BLE frequency band: 2.400–2.4835 GHz
• Radio signal power: 2.5 mW

Bluetooth is used during setup of the Ethernet connection.

IP Camera Compatibility

The recorder supports IP cameras using:

• ONVIF Profile S
• ONVIF Profile T
• RTSP

ONVIF Profile T support is partial.

Ajax cameras and NVRs can also be integrated with compatible third-party video management systems through ONVIF.

Security Protection

The Ajax NVR DC includes tamper protection for professional security installations.

The tamper system can notify users if an attempt is made to:

• Detach the device from the installation surface
• Remove the device from the mounting panel

Access rights can also be distributed between users in Ajax mobile applications and monitoring company operators through PRO Desktop.

Power Supply

The device operates from a low-voltage DC power source.

Operating Voltage

• 9–16 V DC

Without Jumper Installed On PSU Board

• 8–16 V DC
• Up to 4 A
• Turn-on threshold: 8.1 V DC ±0.1 V
• Turn-off threshold: 6.8 V DC ±0.3 V

With Jumper Installed On PSU Board

• 12.3–16 V DC
• Up to 4 A
• Turn-on threshold: 12.4 V DC ±0.1 V
• Turn-off threshold: 10.4 V DC ±0.3 V

Power Consumption

• Up to 24 W

Clock Battery

• CR2032
• 3 V
• Used only to power the system clock

Device Specifications

• Video Channels: 8
• Maximum Resolution: Up to 4K at 25/30 FPS
• Video Decoding: H.265 / H.264
• Bandwidth: Up to 100 Mbit/s
• Ethernet: Up to 100 Mbit/s
• Bluetooth: BLE, 2.400–2.4835 GHz
• Storage: 1 × SATA HDD or SSD
• Maximum Storage Capacity: 16 TB
• Drive Form Factor: 2.5″ or 3.5″
• Maximum Drive Power Consumption: 7 W
• Operating Voltage: 9–16 V DC
• Maximum Power Consumption: 24 W
• Dimensions: 193 × 193 × 47 mm
• Weight: 583 g without drive
• Operating Temperature: 0°C to +40°C
• Operating Humidity: Up to 75%
• Protection Class: IP20
• Installation: Indoor use only
• Colour: White

Compatibility

Compatible with:

• Ajax IP cameras
• IP cameras supporting ONVIF Profile S
• IP cameras supporting ONVIF Profile T where supported
• RTSP-compatible IP cameras
• Compatible third-party video management systems through ONVIF
• Ajax mobile applications
• PRO Desktop

Complete Set

• NVR DC
• SmartBracket mounting panel
• Terminal adapter
• Ethernet cable
• Installation kit
• Quick start guide

HDD or SSD is not included.

Professional Security Solution

The Ajax NVR DC 8-CH White provides centralised video recording and management for professional residential and commercial surveillance installations. Its integration with Ajax alarm events allows compatible detectors and cameras to work together for rapid visual verification of security incidents.
