Ajax MotionCam PhOD Wi-Fi Jeweller White

Ajax MotionCam PhOD Wi-Fi Jeweller White

The Ajax MotionCam PhOD Wi-Fi Jeweller White is an advanced wireless indoor motion detector with built-in photo verification designed for professional intrusion protection. This Ajax MotionCam PhOD device combines PIR motion detection with intelligent visual verification to help users and monitoring companies quickly assess alarm events.

Because the detector captures real-time images when motion is detected, users can instantly verify whether an alarm represents a genuine threat.

Instant Photo Verification

The detector includes a built-in camera for visual event verification.

Photo verification features include:

• Photo by alarm
• Photo on demand
• Photo by schedule
• Photo by scenario

Users can request photos directly through Ajax applications at any time to check the condition of the protected premises.

The detector can also automatically capture images when another Ajax device triggers an alarm.

As a result, users receive visual confirmation within seconds without unnecessary patrol dispatches or false alarm concerns.

Accurate PIR Motion Detection

The Ajax MotionCam PhOD uses a PIR motion sensor designed for reliable human detection.

Detection features include:

• Motion detection range up to 12 m
• Horizontal viewing angle of 88.5°
• Vertical viewing angle of 80°
• Motion detection speed from 0.3 to 2.0 m/s
• SmartDetect false alarm filtering

The SmartDetect algorithm analyses thermal patterns and movement characteristics to minimise false alarms caused by pets and environmental disturbances.

Pet Immunity and Temperature Compensation

The detector includes advanced software filtering and temperature compensation.

Protection features include:

• Pet immunity for animals up to 20 kg
• Effective pet height filtering below 50 cm
• Automatic temperature compensation
• Adjustable sensitivity levels

Consequently, the detector maintains reliable motion detection performance across changing indoor temperatures.

Advanced Wireless Communication

The detector communicates using Ajax Jeweller wireless technology.

Communication features include:

• Encrypted two-way wireless communication
• Wireless range up to 1,700 m
• Frequency hopping protection
• Instant alarm transmission
• Remote configuration through Ajax applications

Therefore, the detector integrates securely into Ajax wireless alarm systems.

Reliable Battery-Powered Operation

The detector operates using pre-installed batteries for autonomous wireless protection.

Power features include:

• 2 × CR123A batteries
• Up to 4 years battery life
• Low battery notifications
• Replaceable batteries

Because the detector operates independently from the property power grid, it remains functional during power interruptions.

Professional Installation and Setup

The detector supports simple installation using the Ajax SmartBracket mounting system.

Installation features include:

• QR code pairing
• Remote configuration
• SmartBracket wall mounting
• Fast commissioning through Ajax apps

The detector performs automatic self-diagnostics and continuously reports system status to the Ajax hub.

Device Specifications

• Device Type: Wireless PIR motion detector with photo verification
• Detection Technology: PIR sensor
• Motion Detection Range: Up to 12 m
• Detection Angles: 88.5° horizontal / 80° vertical
• Motion Detection Speed: 0.3–2.0 m/s
• Pet Immunity: Up to 20 kg and 50 cm height
• Wireless Technology: Ajax Jeweller
• Wireless Range: Up to 1,700 m
• Frequency Band: 868.0–868.6 MHz
• RF Output Power: Up to 20 mW
• Photo Resolutions: 160 × 120, 320 × 240, 640 × 480 px
• IR Backlight: Yes
• Photo Delivery Time: Up to 20 s
• Battery Type: 2 × CR123A batteries
• Battery Life: Up to 4 years
• Operating Temperature: −10 °C to +40 °C
• Humidity: Up to 75%
• Protection Rating: IP50
• Dimensions: 135 × 70 × 60 mm
• Weight: 167 g
• Colour: White

Compatibility

Compatible with:

• Ajax Hub 2 (2G) Jeweller
• Ajax Hub 2 (4G) Jeweller
• Ajax Hub 2 Plus Jeweller
• Ajax Hub Hybrid (2G)
• Ajax Hub Hybrid (4G)
• Ajax ReX 2 Jeweller

Applications

Ideal for:

• Residential intrusion protection
• Commercial indoor security
• Offices and retail stores
• Remote indoor monitoring
• Smart alarm verification systems

What’s in the Box

• Ajax MotionCam PhOD Wi-Fi Jeweller White
• SmartBracket mounting panel
• 2 × CR123A batteries (pre-installed)
• Installation kit
• Quick start guide

Professional Security Solution

The Ajax MotionCam PhOD Wi-Fi Jeweller White provides professional indoor intrusion detection with advanced visual alarm verification. With PIR motion sensing, intelligent photo verification, and encrypted wireless communication, it delivers reliable security protection for residential and commercial installations.
