Ajax KeyPad Outdoor Jeweller Black

Ajax KeyPad Outdoor Jeweller Black

The Ajax KeyPad Outdoor Jeweller Black is a professional wireless outdoor keypad designed for secure and convenient access control within Ajax security systems. This Ajax outdoor keypad allows users to arm and disarm the alarm system without entering the building, making it ideal for gates, entrances, warehouses, and perimeter access points.

Because the keypad is engineered for outdoor installations, it features a weather-resistant enclosure and advanced anti-sabotage protection for reliable year-round operation.

Secure Outdoor Access Control

The keypad provides secure system operation using multiple authentication methods.

Supported authentication options include:

• Passcodes
• Ajax Tag key fobs
• Ajax Pass cards
• Smartphone authentication via Bluetooth

Consequently, authorised users can access and control the security system quickly and securely.

Advanced Jeweller Wireless Communication

The Ajax outdoor keypad uses Ajax Jeweller radio communication technology for secure and reliable wireless connectivity.

Communication features include:

• Two-way encrypted communication
• Dynamic key encryption
• Frequency hopping protection
• Instant event notifications
• Remote configuration through Ajax apps

The communication range reaches up to 1,700 metres in open space between the keypad and hub or range extender.

Weather-Resistant Outdoor Design

The keypad is designed for both indoor and outdoor installations.

Environmental protection features include:

• IP66 weather-resistant enclosure
• IK08 impact protection
• Operating temperature from −25 °C to +60 °C
• Humidity resistance up to 80%

Therefore, the keypad remains suitable for demanding outdoor environments and professional perimeter security applications.

Security Protection Features

The keypad includes advanced protection functions designed to prevent unauthorised access and sabotage attempts.

Security features include:

• Tamper alarm notifications
• Automatic lock after multiple incorrect code attempts
• Protection against spoofing
• Communication loss detection
• Secure SmartBracket mounting system

As a result, the device provides reliable protection for residential and commercial installations.

Flexible Security System Functions

The keypad supports multiple operational modes for advanced security management.

Functions include:

• Arming and disarming security modes
• Group security management
• Automation device control
• Panic alarm activation
• Fire alarm muting
• Entry delay activation

Because of these features, installers can configure the keypad to suit a wide range of security applications.

Power Supply

The keypad operates using pre-installed batteries and supports optional external power.

Power features include:

• 2 × CR123A batteries
• Up to 3 years battery life
• Optional 10.5–14 V external power supply
• Low battery monitoring

The batteries also provide backup operation when external power is connected.

Device Specifications

• Device Type: Outdoor wireless security keypad
• Communication Technology: Ajax Jeweller
• Wireless Range: Up to 1,700 m
• Authentication Methods: Passcodes, Tag, Pass, Bluetooth smartphone
• Frequency Bands: 866–926 MHz
• Protection Class: IP66, IK08
• Operating Temperature: −25 °C to +60 °C
• Humidity: Up to 80%
• Power Supply: 2 × CR123A batteries
• Battery Life: Up to 3 years
• Optional External Power: 10.5–14 V DC
• Dimensions: 170 × 45 × 31 mm
• Weight: 258 g
• Colour: Black

Compatibility

Compatible with Ajax wireless security systems and devices including:

• Ajax hubs
• Ajax range extenders
• Ajax Tag key fobs
• Ajax Pass cards
• Ajax automation devices
• Ajax mobile applications

Complete Set

• Ajax KeyPad Outdoor Jeweller Black
• 2 × CR123A batteries (pre-installed)
• SmartBracket mounting panel
• Installation template
• Installation kit
• Quick start guide

Professional Security Solution

The Ajax KeyPad Outdoor Jeweller Black provides secure outdoor access control for residential, commercial, and industrial security systems. With encrypted wireless communication, weather-resistant protection, and multiple authentication methods, it delivers reliable perimeter security management for professional installations.
